The powerful and high efficiency crusher machine is intended for different kinds of plastic, both hard or soft. It can be also used to crush wood.
Powerful and High Efficiency Crusher
The powerful and high efficiency crusher machine is intended for different kinds of plastic, both hard or soft. It can be also used to crush wood.
It is mainly designed for cable leather, cloth, clothes, yarn, chemical fiber, broken waste recycling and shredding, with a special advantage in crushing the mulch films and greenhouse films. Compared to shredders, it can be used for more kinds of plastic and compared to soft material crusher, it has a higher capacity.
The following data is just for reference:
| Type | 1000 | 1300 |
| Motor (kw) | 110KW | 160KW |
| Starting cabinet | 132kw | 190kw |
| Blade length (mm) | 1000mm | 1300mm |
| Outer Diameter | ￠400mm | ￠600mm |
| Rotary blade Qty | 220*490 H13 | 220*650 H13 |
| Pressure plate length | 490mm | 650mm |
| Shaft rotary speed | 650r/min | 650r/min |
| Bearing | 22224 | 22230 |
| Hydraulic cylinder diameter | ￠100*80 (1 pc) | ￠100*80 (2 pcs) |
| Feeding conveyor motor | 7.5kw, 5.5kw | 11kw, 7.5kw |
| Feeding conveyor size | 1*4m | 1.3*4m |
| Outlet conveyor motor | 3kw, 4kw | 4kw,5.5kw |
| Outlet conveyor size | 1*4m | 1.3*4m |
| Oil pump | 3kw | 3kw |
| Shredded material size | 10-80mm | 10-80mm |
| Capacity | 2-3t | 3-5t |
| Machine size | 11*1.5*1.7m | 12*2*1.78m |
| Machine weight | ~11.5t | ~12.8t |
Working principle:
Powerful and high efficiency crusher through the motor drive the move tool rest do high-speed rotation, and in the process of high-speed rotation of the moving knife knife form shear trend of relative movement, using the knife and shear thus formed between the fixed knife on large pieces of plastic crushing, grinding, crushing. Plastic particle size through the screen mesh on the filter output.
Features:
1) Strong structure, easy to operate & durable
2) Uses high quality HD material especially for making knives of the crushers, the machine stands long use under severe and continuous service conditions.
3) The blades can be ground for many times and can be used repeatedly; Blades base structure is stable and durable.
4) Has protection system with the power supply to ensure the equipment safe
5) Easy to clean and maintain, the hydraulic open device can easily lift up the crusher room, blades and screen can be removed and mounted easily.
Products Details
Customers Feedback
Packing & Shipment
Packing:
Whole film packaging machine; anti-collision package edge; fumigation-free plywood wooden box and pallets with iron binding belt.
Shipment:
We cooperate with SINOTRANS company whose experience in the ocean transportation will guarantee your machine safety. We also provide train transport, especially to Russia, Ukraine and other inland countries.
Payment:
We support T/T, L/C, VISA, Mastercard payment terms with Alibaba Trade Assurance.
Taizhou Amige Machinery CO.,LTD is an automated equipment manufacturer which develops, designs and produces products independently for 20 years already . With standard production plant, our factory covers an area of 15,000 square meters. The company has strong technical support, with 100 skilled technical staff, 20 technical design personnel.
Our main product is including plastic crusher,shredder,dryer,baler and Recycling washing line,Plastic pelletizing line etc. All kinds of plastic material can be cut and recycled by our machine. In addition, We are also committed to making dust treatment equipment and sewage treatment equipment.
We will put our best products recommended to more countries, and develop more distributors in many countries around the world. We are honored to with more international friends develop our glorious business.
Certificates
Exhibition & Customers Visit
FAQ
Q1: What is the Warranty for the machines?
A1: 1 year for free.
Q2: What is the Material?
A2: Stainless steel and carbon steel.
Q3: What material can it crush?
A3: Cans, paint bucket, broken bicycle, broken cars, plastic bucket, waste plastic, thin aluminum cans, and so on.
Q4: Are you manufacturer or trading company?
A4: We are manufacturer in China.
Q5: Where are you located? Can I visit your factory?
A5: We are in Taizhou City, Zhejiang province, China. All our clients,from home or abroad, are warmly welcome to visit us!
In order to have a better understanding of your needs,we need you to provide below information about your product:
1)Which kind of material you are going to deal with? .
2)What are the physical characteristics of the material? Such as size,shape,thickness,solid or hollow and etc.
3)What’s the producing capacity in your requests?
Please advise so we can figure out if our machines are applicable and which models will meeting with your requirement.
